FIGURE 6. A0220 Mounting Details.
FIGURE 7. A0220 Detection Range for a 3 kA Fault.
A0220
DRILL TEMPLATE
Ø9(0.354)
DRILL TEMPLATE
NOTES AND INSTALLATION:
1. ALL DIMENSIONS IN MILLIMETERS (INCHES).
2. AFFIX THE DRILL TEMPLATE WHERE THE SENSOR IS TO BE
MOUNTED.
M4 x 0.7 (8-32)
M5 x 0.8 (10-32)
M4 x 0.7 (8-32)
M5 x 0.8 (10-32)
3 kA 3 kA
