Light Electronic Control DzLCEdz User Manual
Light control manual-ENG-neutro_03.docx Rev. 04 EN 5 / 6
firmware 2.4
EN
1.1. User variables:
MODBUS Point Type: HOLDING REGISTER
Read command: 03 (03Hex)
Write command: 16 (10Hex)
Address
write/read
Description
MODBUS
Value
Um
Default
Min
Max
53274
Modbus protocol controller
address
1
1
1
255
53275
Modbus baud rate protocol
3= 9600 baud (default)
4= 19200 baud
5= 38400 baud
6= 58600 baud
7= 115200 baud
3
3
3
7
53276
Modbus parity protocol
1= EVEN (default)
2= NONE
3= ODD
1
1
1
3
Address
write/read
Description
SET
Value
Um
Default
Min
Max
16389
3 Point Valve Cooling
Proportional Band
2
°C
20
1
100
16390
3 Point Valve Heating
Proportional Band
2
°C
20
1
100
16391
Fan Auto:
Differential Medium Speed
2
°C
20
1
100
16392
Fan Auto:
Differential Maximum Speed
2
°C
20
1
100
16393
Heater Differential
2
°C
20
1
100
16394
Heater Post Ventilation Time
60
Sec
60
10
500
16395
FreeCooling Differential
1
°C
10
1
100
16396
FreeHeating Differential
1
°C
10
1
100
16397
Free Cooling Hysteresis
0.5
°C
5
1
15
16398
User Working Mode:
0 = Cool; 1 = Heat; 2 = Auto
2
2
0
2
16399
On Off Status (Memorized into
EEprom)
0 = Off; 1 = On
0
0
0
1
16400
Fan Control
0 = Min; 1 = Med; 2 = Max; 3 =
Auto
3
3
0
3
16401
Setpoint Cooling
26.0
°C
260
50
350
16402
Setpoint Heating
20.0
°C
200
50
350
16403
Profile 1: Start band 1
08:00
HH:MM
480
0
Profile 1: End band 1
16404
Profile 1: End band 1
12:00
HH:MM
720
Profile 1: Start band 1
1439
16405
Profile 1: Start band 2
14:00
HH:MM
840
0
Profile 1: End band 2
16406
Profile 1: End band 2
17:00
HH:MM
1020
Profile 1: Start band 2
1439
16407
Profile 2: Start band
08:00
HH:MM
480
0
Profile 2: End band
16408
Profile 2: End band
17:00
HH:MM
1020
Profile 2: Start band
1439
16409
Profile 1: Set Cool Band 1
26.0
°C
260
Profile 1: Set Heat Band 1
350
16410
Profile 1: Set Cool Band 2
26.0
°C
260
Profile 1: Set Heat Band 2
350
16411
Profile 2: Set Cool Band
26.0
°C
260
Profile 2: Set Heat Band
350
16412
Profile 1: Set Heat Band 1
20.0
°C
200
50
Profile 1: Set Cool Band 1
