LMF Clima LCE - Page 13

Light Electronic Control DzLCEdz User Manual
Light control manual-ENG-neutro_03.docx Rev. 04 EN 6 / 6
firmware 2.4
EN
16413
Profile 1: Set Heat Band 2
20.0
°C
200
50
Profile 1: Set Cool Band 2
16414
Profile 2: Set Heat Band
20.0
°C
200
50
Profile 2: Set Cool Band
16415
Monday Profile Selection
1 = P1; 2 = P2; 3 = P3; 4 = P4
1
1
1
4
16416
Tuesday Profile Selection
1 = P1; 2 = P2; 3 = P3; 4 = P4
1
1
1
4
16417
Wednesday Profile Selection
1 = P1; 2 = P2; 3 = P3; 4 = P4
1
1
1
4
16418
Thursday Profile Selection
1 = P1; 2 = P2; 3 = P3; 4 = P4
1
1
1
4
16419
Friday Profile Selection
1 = P1; 2 = P2; 3 = P3; 4 = P4
1
1
1
4
16420
Saturday Profile Selection
1 = P1; 2 = P2; 3 = P3; 4 = P4
2
2
1
4
16421
Sunday Profile Selection
1 = P1; 2 = P2; 3 = P3; 4 = P4
4
4
1
4
16422
Profile Enabled
0 = Off; 1 = On
0
0
0
1
16423
Antifreeze Setpoint (rev 2.1)
5.0
°C
50
-50
150
16424
Antifreeze Differential (rev 2.1)
1.0
°C
10
1
50
Address
read
Description
Input-Output
Value
Um
Default
Min
Max
8192
State On-Off digital input (DI1)
0 = On; 1 = Off
0
0
0
1
8960
Regulation Sensor Temperature
17.5
°C
0
-500
1100
8961
Current Fan Speed
0 = Off; 1 = Min; 2 = Med; 3 = Max
0
0
0
3
8962
Three Point Cold or Changeover
Valve Estimated Position
0.0
%
0
0
1000
8963
Three Point Hot Valve Estimated
Position
0.0
%
0
0
1000
8964
Heater Status
0 = Off; 1 = On
0
0
0
1
8965
External Bypass Status
0 = Off; 1 = On
0
0
0
1
8966
Fresh Air Temperature
11.2
°C
0
-500
1100
8968
On Off Status
0
0
0
1
Address
read
Description
Allarm
0= Not Active
1= Active
2=Manual Reset
Value
Um
Default
Min
Max
9000
Suplpy Air Sensor Error
0
0
0
1
9001
Fresh Air Sensor Error
0
0
0
1
9002
SKW Display Sensor Error
0
0
0
1
9003
Filter Alarm
0
0
0
1
9004
Heater Overheating Alarm
(Manual Reset)
0
0
0
2
9005
Antifreeze Alarm (rev 2.1)
0
0
0
1
Address
read
Description
Version
Value
Um
Default
Min
Max
9471
Application version
2.1
21
Note:
(divided 10, °C) divide the value by 10, the result is in degree Celsius with one decimal place (Es: 175= 17.5°C)
(divided 10, %) divide the value by 10, the result is in percentage with one decimal place (Es: 505= 50.5%)
(HH:MM) minutes starting from midnight where 0= 00:00 e 1439= 23:59 (In example: 120= 02:00; 1170= 19:30)
