4.2.2 Suction Lift - Wall Bracket Mount
The pump may be mounted using an LMI Wall Mount Bracket
Assembly (part no. 34643) directly above the solution tank.
A pump mounted in this manner allows for easy changing of
solution tanks or drums.
Injection
Check Valve
Pressure
Line
2.0 in. (50 mm)
Space for Sediment
Accumulation
Solution
Tank
LMI Pump
Front Mount
LMI Pump
Rear Mount
Tee
