LMI PW5 - Page 14

14
4.2.4 Suction Lift - Shelf Mount
The pump may be mounted on a shelf (customer supplied)
maintaining a suction lift of less than 5 ft (1.5 m). An LMI
mounting kit (part number 10461) is available for securing the
pump to a shelf.
Flow
Injection Check
Valve
Anti-Syphon
Pressure Relief
Valve
(Optional Accessory)
LMI Pump
Solution
Drum
2.0 in. (50 mm)
Space for
Sediment
Accumulation
Flow
