Prepare door and remove existing lock. If necessary, use provided Installation
Template to prepare door.
1-⅜" (35mm)
to 2" (50mm)
3-⅞" (22mm)
2-⅜" (60mm)
*½"
12mm
4-⅛" (54mm)
3-3/4" (98mm)
* You are not required to drill a hole in your door. We have provide double sided adhesive
tape for you to help stabilize the lock during installation. Only drill a hole if you wish to have
added stability. Please refer to the provided templates for drilling if needed.
Optional: Door Hole Drill
3
Preparation
Phillips
Screwdriver
To complete the installation you will need:
Tape measure
or ruler
To Next Page
