Lockly Secure LUX Installation Manual

PARTS LIST
Interior Panel Screw (1)
Screw for Inner Panel (2)
Positioning Sleeve (1)Lock Cylinder Screw (2)
Wrench(X1)
Cotter Pin (1)
50~60MM STANDARD DOOR THICKNESS
Screw for Lockset (4)
Strike Screw (2) Screw Cap (2)
Escutcheon Screw Pad (2)
Position Pad (2)
Shaft (1)
Cotter Pin hole is here
when door thickness is
larger than 70mm
Cotter Pin hole is here
when door thickness is
less than 70mm
Turnable Flat Strip (1)
Buckle Box (1)
Strike (1)
Lock Cylinder (1)
Stabilizing Screw (2) Screw for Exterior Panel (2)
