Lockly Secure LUX Installation Manual

LEFT IN-SWING DOOR
Make sure the latch throw is
correctly oriented as shown to fit
your left in-swing door
Make sure the pit hole is
correctly oriented as shown.
KNOW YOUR DOOR
- This lock is suitable for wooden doors and steel doors with a thickness of 40~120mm.
- First you must identify the opening direction of your door before installation.
- Adjust the direction of the corresponding lockset to fit your door with the exterior and
interior panels.
Follow the steps on the next pages to adjust your latch throw, cylinder
and door handle.
IMPORTANT NOTICE
LEFT OUT-SWING DOOR
Make sure the latch throw is
correctly oriented as shown to fit
your left out-swing door
Make sure the pit hole is
correctly oriented as shown.
