3
LockUp Lock Parts
Note: Conrm that all lock parts are present. If there are damaged or missing parts contact your
LockUp Product Support Specialist.
Required Components
1-Rear Unit1-Front Unit 2-Locking Nuts Optional-Back Plate
Warning: Do not use an electric screw gun during installation of the
lock unless equipped with a torque adjuster, which must be set on a
low torque setting. Otherwise, damage may be caused to the lock.
Required Tools
3/8” Socket
(deep socket required)
Phillips Screwdriver
Head Size #1 & #2
Hack Saw Metal File
For padlock hasp removalFor lock installation
