Configuration examples
Configuration examples
Only one of the given examples is possible at the same time.
Connection option without Loewe klang link (2.0/3.0 system)
When configuring a 2.0/3.0 system, the Loewe klang 9 will be connected to the
audio source via DIGITAL AUDIO LINK.
How to connect the speaker via DIGITAL AUDIO LINK is described on page 10.
An example of a 2.0/3.0 system
A set-up example of a 2.0/3.0 system
DIGITAL AUDIO LINK
TV-set
Front
right
Front
left
TV speaker
as centre speaker
Front
left
Front
right
TV speaker
as centre speaker
Connection option without Loewe klang link (5.0 system)
When configuring a 5.0 system, the Loewe klang 9 will be connected to the audio
source via DIGITAL AUDIO LINK.
How to connect the speaker via DIGITAL AUDIO LINK is described on page 10.
An example of a 5.0 system
A set-up example of a 5.0 system
DIGITAL AUDIO LINK
TV-set
TV speaker
as centre speaker
Front
right
Front
left
Surround
ri
g
ht
Surround
left
Front
left
Front
right
TV speaker
as centre speaker
