23
Technical data
Connections
Mini-DIN (Front) Video IN Y/C (S-VHS/Hi8)
Cinch (Front) Video IN CVBS (VHS/8mm)
Cinch (Front) Audio IN L/ R
Jack 6,3mm (Front) headphones 32–200 Ohm
IEC socket 75 Ohm antenna/cable/DVB-T
✳
F-socket 75 Ohm
✳
SAT and SAT A/D
AV 1 Video IN/OUT Y/C (S-VHS/Hi8)
Video IN/OUT CVBS (VHS/8mm)
Audio IN/OUT L/ R
AV 2 Video IN/OUT
✳✳
Y/C (S-VHS/Hi8)
Video IN/OUT CVBS (VHS/8mm)
Video IN RGB
Audio IN/OUT L/R
Cinch Audio OUT level adjustable/fi xed
9-pole cube socket
✳
active loudspeaker systems
Mini-DIN 8-pole Service or Loewe audio systems
✳
depending on equipment and type of set or
retrofi ttable
✳✳
OUT only in Digital Link Plus video recorders
Electrical data
Chassis name Media Plus (Q2500/B)
Image refresh frequency PAL/SECAM 100 Hz
PAL 60/NTSC 120 Hz
Full Digital 100 AMD
✳
/DNC
Power supply 220V up to 240V/50–60Hz
Power consumption in operation approx.145 Watt
Standby <2.5 Watt
Sat-Record-Mode <60 Watt
Ambient temperature 5º – 40º Celsius
Tuner VHF/UHF/ cable
(Hyperband 8 MHz) 42 MHz – 860 MHz
Station memory
✳
220/with DVB:1470
TV norms
✳
B/G, I, DK, L, L‘, M, N
Color norms
✳
PAL, SECAM,
NTSC, NTSC 4,43
Sound norm
✳
FM, AM, Nicam
mono/stereo/2-sound
Audio rated output 2 x 12 Watt / 8 Ohm
Audio music output 2 x 20 Watt / 8 Ohm
Teletext HiText (Level 2.5)
Mechanical data
Aventos 3770 ZW Article no. 63447
Aventos 3970 ZW Article no. 62407
Dimensions (cm) 72,5 x 53,5 x 49,5 (WxHxD)
Weight (kg) 38,5
Picture tube Real Flat-Line
Format 16:9
Screen class 70 cm, visible 66 cm
Aventos 3772 Z Article no. 63446
Aventos 3972 ZP Article no. 62406
Dimensions (cm) 74,0 x 59,5 x 49,5 (WxHxD)
Weight (kg) 44
Picture tube Real Flat-Line
Format 4:3
Screen class 72 cm, visible 68 cm
Aventos 3781 ZW Article no. 63454
Aventos 3981 ZW Article no. 64433
Modus C 32 Article no. 64432
Dimensions (cm) 81 x 59,5 x 55,5 (WxHxD)
Weight (kg) 53
Picture tube Real Flat-Line
Format 16:9
Screen class 81 cm,visible 76 cm
32190_021_3_GB 23 18.10.2004, 15:40:15 Uhr
