Loewe Profil Plus 3272Z - Page 17

BILDROHRPLATTE Art.-Nr.: 86429.050
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nummer
Item N ° . List Part N ° .
Buchsen/Fassungen Sockets
W 0000Bildrohrfassung.........................picture tube socket......320-24766
Integr.schaltungen Integrated circuits
I 3001 TEA 5101 B STM......................integrated circuit.........349-24517
Transistoren Transistors
Q 3521 BC 640......................................transistor.....................346-25720.020
Q 3522 BC 639......................................transistor.....................346-75622.020
Dioden Diodes
D 3553 BA 157......................................diode...........................352-44799
Potentiometer Potentiometers
P 3362 2M2..........................................potentiometer..............375-17337
P 3401 10K...........................................potentiometer..............375-15665
Kondensatoren Capacitors
10N M 2000V............................capacitor.....................357-21868
22U S 250 V.............................electrolyt capacitor......360-11762.020
22U S 250V..............................electrolyt capacitor......360-11762
C 3222 100P M 1 KV............................capacitor.....................357-18178.020
C 3364 1N M 1000V..............................capacitor.....................357-73102
C 3367 100N K 250V............................capacitor.....................359-74632
C 3553 100P K 500V............................capacitor.....................357-20272.020
Widerstände Resistors
R 3100 3R3 J 0,25W 0207....................resistor........................366-77754
R 3113 1K5 K 0411...............................resistor........................365-77586
R 3116 100K F 0207.............................resistor........................367-23700
R 3213 1K5 K 0411...............................resistor........................365-77586
R 3216 100K F 0207.............................resistor........................367-23700
R 3222 1K5 K 0411...............................resistor........................365-77586
R 3313 1K5 K 0411...............................resistor........................365-77586
R 3316 100K F 0207.............................resistor........................367-23700
R 3362 1M J 0617.................................resistor........................366-16901
R 3363 1K5 K 0411...............................resistor........................365-77586
R 3364 1M J 0617.................................resistor........................366-16901
R 3366 100R J 0309.............................resistor........................366-17757
R 3400 4R7 K 0207...............................resistor........................366-18416
R 3553 3R3 K 0207...............................resistor........................366-11790
SMD-Bauteile SMD parts
BA 582 SMD.............................diode...........................351-17995
BC 847 B SMD.........................transistor.....................344-14974
BC 857 B SMD.........................transistor.....................344-14979
LL 4148 SMD............................diode...........................351-15015
Q 3557 BC 856 B..................................diode...........................344-23759
