72
The maximum time a heater can stay on depends on the selected cooking level.
Power
level
Max.
time on
(hours)
1 10
2 5
3 5
4 4
5 6
6 2
7 2
8 2
9 1
3.8. GLASS CERAMIC WORKTOP
The new design concept heating elements make it possible to reach maximum power in a few
seconds. Furthermore, the ultra-thick fibreglass insulation prevents heat dispersion, limiting
heating to the silk screen-printed zones only. The 4 (or 5) heating zones are controlled by 2
switches and 2 (or 3) energy regulators.
The switch controls power in W, which is pre-defined according to the position set on the knob.
The energy regulator is a device which regulates power gradually according to the position set
on the knob ( % of maximum power). Control of the heating zones is automatic, by activating or
disabling the heating elements at regular intervals, thus ensuring precise, uniform heating. E.g.:
short heating periods and long pauses indicate low temperature; long heating periods and brief
pauses indicate a higher temperature. With the energy regulator, you can totally or partially
heat a particularly zone of the glass ceramic top.
Plate lay-out (see tables)
Characteristics of the heating zones in 4 heating plate kitchen ranges.
Knob position and relevant power
Position
Type of
command
Effective
heated zone
Knob
rotation
max
power
1 2 3 4 5 6
All
Clockwis
e
2200W
Front left
Energy
regulator
Central
anti-
clockwise
750W
10 % 25 % 50 % 65 % 90 % 100 %
Rear left Switch
All
anti-
clockwise
1200W 150 W 200 W 350 W 500 W 850 W 1200 W
Front right Switch
All
anti-
clockwise
1700W 180 W 300 W 450 W 750 W 1200 W 1700 W
All
Clockwis
e
2400W
Rear right
Energy
regulator
Circular
anti-
clockwise
1500W
10 % 25 % 50 % 65 % 90 % 100 %
Absorbed electric power
