Lofra MT96MF/C - BURNER SPECIFICATIONS

77
TABLES
BURNER SPECIFICATIONS TABLE 1
Gas type: Butane G30 - Nominal pressure =28-30mbar
Propane G31 - Nominal pressure =37mbar
Methane G20 - Nominal pressure =20mbar
Liquid gas/LPG Natural gas
Nominal thermal capacity
g/h max g/h min
Nominal
Thermal
capacity
Type of burner
By
pass
Ø
1/100
mm
Injectors
Ø 1/100
mm
kW
max
G30 G31
kW
min
G30 G31
Inje
ctor
Ø
1/10
0
mm
kW
max
kW
min
Cooking hob burners I series
Auxiliary (small) 27 50 1,00 73 71 0,29 21 21 77 1,00 0,29
Semi – rapid: (medium) 29 65 1,75 127 125 0,35 25 25 97 1,75 0,35
Rapid: (large) 39 85 3,00 218 214 0,60 44 43 127 3,00 0,50
Treble crow 65 100 3,90 283 278 1,50 109 106 136 3,90 1,50
Fish Kettle 65 85 3,00 218 214 1,50 109 107 120 3,00 1,50
Cooking hob burners II series normal e AEO, four-leaf clover
Auxiliary (small) 27 50 1,00 73 71 0,30 21 21 72 1,00 0,30
Semi – rapid: (medium) 34 65 1,75 127 125 0,44 25 25 97 1,75 0,44
Rapid: (large) 44 85 3,00 218 214 0,75 44 43 115 3,00 0,75
Treble crow 65 100 3,90 283 278 1,50 109 106 136 3,90 1,50
Dual Ø125mm: 70 46/85 3,90 283 278 1,80 130 127 130/75 3,90 1,80
Dual Ø145mm: 27/65 46/95 4,5 326 319 1,80 130 127 130/85 4,20 1,80/0,35
Dual four-leaf clover 27/70 46/66 4,2 304 297 0,30 22 22 66/1,02 4,20 0,30
Cooking hob burners III series
Auxiliary (small) 27 52 1,10 79 78 0,35 25 25 73 1,10 0,35
Semi – rapid: (medium) 34 65 1,75 127 125 0,45 32 32 98 1,75 0,45
Rapid: (large) 44 82 2,80 203 200 0,75 54 53 122 2,80 0,75
Treble crow 65 97 3,70 268 264 1,50 109 133 133 3,70 1,50
Gas oven burners
60L : (60x50-60x60-70x50-
70x60) – Sliding Trolley (80x60
– 90x60)
55
85
countersink
hole
3,30 240 236 1,10 80 79
130
coun
tersi
nk
hole
3,30 1,10
