Lofrans PROGRESS ONE - Parts List; Comprehensive Windlass Parts List

CODE B.16.102A DATE : MARCH 2002
PROGRESS ONE PARTS LIST - U.S.A. VERSION
Item Description Qty Item Description Qty
203a Viton Seal 35-45-7 1 517 Stripper 1
209 Key 6x6x30 1 518a Base 1
226 Washer ∅8 5 518b Chromed bronze base 1
227 Nut M8 4 519 Gipsy cap 1
242 Cap nut M8 1 888 Screw 1
260 Spring washer ∅8 4 889 Pivot 1
272 Handle 1 890 Spring 1
273 Clutch nut 1 891a Finger 1
274a Drum 1 891b Chromed bronze finger 1
274b Chromed bronze drum 1
275 Washer 1
278 Seal 25-47-7 1
279 Circlip 47 Din 472 1
280 Circlip 25 Din 471 2
281 Bearing 16005 1
282 Main shaft 1
283 Key 6x6x80 1
284 Key 8x7x60 1
292 Stud M8x76 4
293 Hd cap screw M5x16 5
294 Gearcase - upper 1
295 O Ring seal 4387 1
296 Seal 40-56-8 1
297 Bearing 16008 2
298 Circlip 78 Din 472 1
299 Iron key 6x6x30 2
300 Sleeve 1
301 Spring 1
302 Dog clutch 1
303 Wormwheel 1
304 Seal 40-55-7 1
305 Gearcase - lower 1
306 Nut M6 2
307 Spring washer ∅6 2
308 Washer ∅6 2
309 Bearing 6203 1
310 Worm 1
311 Thrust bearing 51105 1
312 Circlip 43 Din 472 1
313 Seal 25-43-9 1
314 Key 5x5x15 1
315a Electric motor 700 W 12 V 1
315b Electric motor 700 W 24 V 1
315c Electric motor 1000 W 12 V 1
315d Electric motor 1000 W 24 V 1
319 Seal 25-42-6 1
508 Lock nut 1
509 Seal 3112 1
510 Washer 1
511 Clutch cone - outer 1
512 Gipsy ∅8 Iso - 5/16” G40 -5/16” BBB 1
513 Clutch cone - inner 1
514 Main shaft 1
515 Hd cap screw M8x25 2
516a Cover 1
516b Chromed bronze cover 1
