Logan F300-1 - Studio Joiner Assembly Procedure

3
Logan Graphic Products Inc., 1100 Brown Street, Wauconda, IL 60084 Toll Free 1 800 331 6232 www.logangraphic.com
Assembly Procedure
1. Slide support rods into sleeves in board (Fig. 1).
2. Attach support rods with rod screws and
washers using rod wrench (Fig. 2).
3. Slide lever assembly over support rods (Fig. 3).
4. Screw knobs into lever assembly (Fig. 4).
Instruction Manual
Model F300-1
Studio Joiner
Fig. 1
Fig. 2
Fig. 3
Fig. 4
