9
Remote Control Operation Range
• The remote control sensor at the front unit is
sensitive to the remote control’s commands up
to a maximum of 6 metres away and within a
maximum of a 40° arc.
• Please note that the operating distance may
vary depending on the brightness of the room.
SOURCE
MUTEVOL –
VOL +
EQ
20° 20°
Max. 6 m
Wall Mounting
1. Remove the screws from the main unit.
2. Attach the wall brackets to the main unit with the screws removed from the main unit.
Wall bracket
Screw
L32S14_IB_140828_will.indd 9 28/8/14 2:37 PM
