11
2. Drill 2 parallel holes (Ø 3-8 mm each according to wall type) in the wall. They should be
parallel to each other. The distance between the holes should be 436 mm.
3. Firmly x 1 dowel into each hole in the wall if necessary.
4. Leave a 9 mm gap between the wall and the screw’s head. Lift the unit over the heads of
the screws and slot into place.
9 mm
436 mm
L32SBT17_IB_Final180629V4.indd 11 29/6/2018 10:33 AM
