Installing the Built-in Oven
1. The space where the oven will be placed needs to be at least 600mm wide, 555mm deep and 720mm high.
600mm
715mm
700mm
595mm
20mm
555mm
575mm
720mm (Min)
B
B
C
C
A
A
If you are placing your oven in an
oven housing you will not need to
use bracket A. Attach brackets B and
C then secure the oven to your oven
housing using 4 screws.
