19
INSTALLATION
GB
3. Do not connect the unit to the mains socket
before installation. Ensure you are not installing
the unit right in front of the mains socket. This
is to avoid potential damage to the back of the
unit.
Power
Delay
Start
1/2 Load
3in1 Inten Normal Eco 1 Hour Glass Rapid
3
in
1
4. The condensation strip must be fitted to
the underside of the worktop above your
dishwasher to protect it against any moisture. Its
purpose is to protect your worktop’s underside
from steam rising from the dishwasher.
Remove the backing paper from the
condensation strip.
5. Stick the condensation strip to the underside of
the worktop.
Leave some space
Stick the Condensation
Strip under the worktop,
where you want to install
the dishwasher.
Ensure the surface is clean prior to
sticking the condensation strip to the
underside of the worktop.
Failure to attach the condensation
strip could result in damage to the
underside of your worktop!
