8
INSTALLATION
GB
4. Ensure there is clearance each side of the
unit to allow slight sideways movement for
servicing when required. Good levelling is
essential for correct closure and sealing of the
door. When the unit is correctly levelled, the
door should not catch the inner liner on either
side of the cabinet. The feet may be adjusted
in order to obtain the optimum levelling of
the unit.
3. Fix the plinth on the plinth tab. Adjust the
plinth height as necessary, the adjustable
range is from 56 mm to 122 mm.
5. If required, the worktop of the dishwasher can
be removed. The height without the worktop
is 820 mm, the minimum dimensions required
to accommodate the dishwasher within fitted
kitchen furniture units.
Do not connect the unit to the mains socket
before installation. Ensure you are not
installing the unit right in front of the mains
socket. This is to avoid potential damage to
the back of the unit.
