Product Overview
Front view
Upper basket
Internal view
Rear view
Lower basket Cutlery basket
Control panel
Water inlet
(connect to
supply hose)
Drain hose
Mains cable (connect to
mains socket)
* All images are for reference only; please refer to your individual unit for actual item.
Spray arm
Rinse aid dispenser
Spray arm
Salt reservoir
Detergent dispenser
Cutlery basket
Filtering system
Cup Racks
Spikes
