Logitech G G923 User Manual

13 ENGLISH
Audio Eects
Only available for TRUEFORCE supported games.
Controlstheoverall strength of the audio-related eects
(enginenote, rumble strips etc.) when using TrueForce-
compatible titles.
If you are using your G923 in older titles that do not support
TRUEFORCE then adjustment of the force feedback can be
performed from the settings menus of the game title.
G HUB PEDALS SETTINGS
Sensitivity
Alters the output response of the pedals to be more or less
sensitive. Leaving this slider at 50% will provide a linear
1:1output. Between 51% and 100% will make the pedal
increasingly more sensitive around the initial movement
of thepedal. Between 0% and 49% will make the pedal
decreasingly sensitive around the initial movement of the Pedal.
Combined Pedals
If checked, this will set the gas and brake pedals to become
twohalves of a single axis. This will help the pedals operate
correctly in older racing titles that do not support separate axes
for pedals.
Note: if left checked then the pedals will not behave correctly
in modern racing titles. If you nd that just one of your pedals
is functioning by accelerating when pressed and braking
whenreleased then you should make sure that this option
isnotchecked.
QUESTIONS?
logitechG.com/support/g923-xb1
TESTING YOUR WHEEL AND PEDALS
On the wheel and pedals screens in G HUB you can check every
button and axis on your G923 in order to ensure everything is
functioning correctly. For the wheel you can also see the eect
ofaltering the Operating range.

Logitech G G923 Specifications

General

Type	Racing Wheel
Compatibility	PC, PlayStation 4, PlayStation 5
Rotation	900 degrees
Connection	USB
Force Feedback	TRUEFORCE
Pedals	Three (Throttle, Brake, Clutch)
Buttons	24-point selection dial
Shifter	Optional (sold separately)
Mounting	Built-in clamps
Power Supply	Power adapter
Weight	2.25 kg (wheel), 3.1 kg (pedals)
Dimensions	260 mm x 278 mm x 270 mm (wheel), 167 mm x 428.5 mm x 311 mm (pedals)
Material	Leather and metal
