Logitech FLIGHT YOKE SYSTEM User Manual

12 English
FLIGHT YOKE CONTROLS AND CORRESPONDING FUNCTIONS
IN MICROSOFT FLIGHT SIMULATOR
Function Default function in FS9 and FSX
Yoke axis X axis Ailerons
Y axis Elevator
Main Buttons Button 1 Brakes (apply/release)
T1 (button 3) Elevator trim down
T2 (button 4) Elevator trim up
T3 (button 5) Flaps retract incrementally
T4 (button 6) Flaps extend incrementally
T5 (button 7) Knee board display/hide
T6 (button 8) Landing gear up/down
Button 2 Views (cycle)
POV Panoramic viewing
Other Controls Mode switch Switch Mode when programming
software is running
Clock Buttons Function Clock / stopwatch swap
Start/Stop Start/stop stopwatch
Reset Reset stopwatch

Logitech FLIGHT YOKE SYSTEM Specifications

General

Type	Flight Yoke System
Compatibility	PC
Throttle Quadrant	Yes
USB	Yes
Connectivity Technology	Wired
Rotation	180 degrees
Throttle Control	Yes
Hat Switch	8-way
Controls	Throttle, Propeller, Mixture
