Logitech G502 Lightspeed User Manual

LIGHTSPEED BATTERY LIFE
G502 LIGHTSPEED has a rechargeable 250mAH LiPol battery which provides it with up to 55 hours of non‑stop
gaming at 1ms report rate with lights off, or 48 hours non‑stop gaming at 1ms report rate with RGB color cycling on *
– Charge level can be checked when the mouse is powered on or by pressing the G9 button or using Logitech G
HUB to assign a button to check charge level
– Charge level is displayed for seven seconds at mouse power‑on using the color and number of bars illuminated on
the DPI indicator:
– 3 green lines = 50–100%
– 2 green lines = 30–50%
– 1 green line = 15–30%
– 1 flashing red line = <15%
Tips:
– The bottom dot will flash red when the battery is at 15% or less When this happens, plug in your mouse to charge
– Charge level, power draw, and estimated remaining battery life can be checked in Logitech G HUB
* Battery life and capacity may vary with age and use Rechargeable batteries have a limited number of charge cycles

Logitech G502 Lightspeed Specifications

General

Purpose	Gaming
Scroll type	Wheel
Buttons type	Pressed buttons
Polling rate	1000 Hz
Frequency band	2.4 GHz
Buttons quantity	11
Device interface	RF Wireless
Acceleration (max)	40 G
Movement detection technology	Optical
Customizable movement resolution	Yes
Form factor	Right-hand
Product color	Black
Illumination color	Multi
Balance weight	16 g
Battery type	Built-in battery
Power source	Batteries
Charging port type	Micro-USB Type-B
Other operating systems supported	ChromeOS
Windows operating systems supported	Windows 7
Wireless receiver interface	USB Type-A
Package depth	115 mm
Package width	68 mm
Package height	172 mm
Package weight	430.4 g
Master (outer) case width	147 mm
Master (outer) case height	188 mm
Master (outer) case length	244 mm
Master (outer) case weight	1908 g

Weight and Dimensions

Depth	132 mm
Width	75 mm
Height	40 mm
Weight	114 g
