Logitech G502 SE User Manual

6 English
6
After inserting the weights, close the weight
door by inserting the tabs on the weight
door into the slots on the left side of
the mouse and rotating the door down
until the magnet holds the weight door
firmly closed.
7
Out of the box, the sensor for the G502
is configured to deliver amazing
tracking across a wide range of surfaces.
For an extra edge, it can also be further
tuned for optimal performance with the
specific surface that you use for gaming.
To tune the sensor, use the Logitech
Gaming Software.

Logitech G502 SE Specifications

General

Sensor	HERO
Max acceleration	> 40 G
Max speed	> 400 IPS
USB report rate	1000 Hz (1ms)
Buttons	11
Weight	121g (mouse only)
Connection	Wired
Cable Length	2.1 m
Dimensions	132 mm x 75 mm x 40 mm
DPI Range	100 - 16, 000 DPI
Weight Tuning	Up to 18g (5x 3.6g weights)
RGB Lighting	Yes
