Logitech H570e Setup Guide

HEADSET FIT
Adjust headset by sliding headband open
or closed.
ADJUSTING THE MICROPHONE BOOM
1 Microphone boom rotates 270 degrees.
Wear it on either left or right side.
2 Adjust exible microphone boom location
to capture voice better.
WHAT’S IN THE BOX
MONO
1 Headset with In-line controller
andUSB-A connector
2 User documentation
STEREO
1 Headset with In-line controller
andUSB-A connector
2 User documentation
USB-A
USB-A
CONNECTING THE HEADSET
Plug the USB-A connector into
yourcomputer USB-A port.
4 English

Logitech H570e Specifications

General

Headset type	Binaural
Product type	Headset
Plug and Play	Yes
Product color	Black
Wearing style	Head-band
Recommended usage	Office/Call center
Sound pressure level (max)	79 dB
Connectivity technology	Wired
Impedance	- Ω
Magnet type	-
Ear coupling	Supraaural
Headphone frequency	31.5 - 20000 Hz
Headphone sensitivity	94 dB
Total Harmonic Distortion (THD)	5 %
Microphone type	Boom
Microphone frequency	100 - 18000 Hz
Microphone sensitivity	-47 dB
Quantity	1
Package depth	180 mm
Package width	60 mm
Package height	200 mm
Package weight	194 g
Master (outer) case width	210 mm
Master (outer) case height	380 mm
Master (outer) case length	370 mm
Master (outer) case weight	2730 g
Mac operating systems supported	Mac OS X 10.6 Snow Leopard
Windows operating systems supported	Windows 7, Windows 8

Weight and Dimensions

Depth	50 mm
Width	165 mm
Height	172 mm
Weight	111 g
