Logitech PRO RACING WHEEL - Racing Seat Mounting

5 ENGLISH
2 RACING SEAT
2a. Use the three bolt holes on the
underside of the PRO Racing wheel to
attach it to most major racing seats.
– You will need 3 x M6X1 bolts (not
included) with a maximum depth
inside the wheel base of 15mm.
Remember to account for the
thickness of the surface that you
are attaching the wheel base to.
– Using a longer bolt than this will
damage the wheel unit, so use
washers if needed to ensure that
the bolts do not encroach too far
inside the wheel base.
– You only need to hand tighten.
Do not use power tools to tighten
the bolts.
2b. You can use the included cover to ll
the clamp hole when attaching to
a racing seat.
WARNING:
– Do not use the wheel rim as leverage
to assist you when getting into or out
of your racing seat as this will damage
your PRO Racing Wheel.
M6X1
M6X1 L = T + 15MM
T L
2a
2b
