General| Pan range | -25 - 25 ° |
|---|---|
| PTZ control | Yes |
| Product type | Group video conferencing system |
| Product color | Graphite |
| Tilt angle range | -15 - 15 ° |
| Number of persons | - person(s) |
| Megapixel | - MP |
| Sensor type | - |
| Digital zoom | 3 x |
| Optical zoom | 5 x |
| Image sensor size | - \ |
| Diagonal field of view | 90 ° |
| Vertical field of view | 52.2 ° |
| Horizontal field of view | 82.1 ° |
| Remote control interface | Bluetooth |
| Maximum frame rate | 30 fps |
| Supported video modes | 576p, 720p, 900p, 1440p, 2160p |
| Microphone frequency | 90 - 16000 Hz |
| Number of microphones | 6 |
| Microphone sensitivity | -36 dB |
| Microphone direction type | Omnidirectional |
| Sound pressure level (max) | 90 dB |
| Output level | 92/99 dB |
| Sample rates | 0 - 48 kHz |
| RMS rated power | 8 W |
| Microphone pick-up range | 4.5 m |
| Output voltage Total Harmonic Distortion (THD) | 2 % |
| Telepresence | No |
| USB connector type | USB Type-A, USB Type-C |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI output ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| Heat dissipation | 64 BTU/h |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 95 % |
| Current | 4.754 A |
| Power plug type | Type C |
| AC input voltage | 100 - 240 V |
| Battery capacity | 220 mAh |
| DC input voltage | 19 V |
| Power source type | AC |
| Battery technology | Lithium |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Security algorithms | 128-bit AES |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| Supported network protocols | IPv4, IPv6 |
| Cables included | AC, DC, HDMI, USB Type-A to USB Type-C |
| HDMI cable length | 2 m |
| Power cable length | 2.5 m |
| Master (outer) case width | 220 mm |
| Master (outer) case height | 231 mm |
| Master (outer) case length | 1004 mm |
| Master (outer) case weight | 9909 g |
| Mac operating systems supported | Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey |
| Windows operating systems supported | Windows 10, Windows 11 |
Weight and Dimensions| Depth | 160 mm |
|---|---|
| Width | 910 mm |
| Height | 164 mm |
| Weight | 7080 g |
| Package depth | 989 mm |
| Package width | 207 mm |
| Package height | 218 mm |
| Package weight | 9305 g |
