30
13
14
15
Remove the saw template and loosen the
screws that hold the guide rail holder. When
the guide rail holder has been lowered down
to the aluminium angle iron, you fasten it
for the next cut. Repeat all the steps at the
other end of the log.
Now you can make the next cut.
By repeating the steps 12-15, you can cut up
the log into the desired number of boards
and dimensions.
