13
Fig. 86
Fig. 87
Fig. 88
7. Start the feed with the power switch (49). The
feed cam wheel (K) should rotate anticlockwise. If
this is not the case, the connection cables have
been interchanged.
8. Stop the feed and check where the grinding disc
goes down against the bandsaw blade.
9. Adjust the knob (L) until the grinding disc just
touches the inside of the saw tooth (M). Points 7
and 8 above may need to be repeated.
10. Insert the lifter (N) in the appropriate hole in the
lever (O) and start the feed. Adjust the knob (P)
until the grinding disc just touches the entire
tooth valley while fed.
11. Stop the feed and turn both knobs 1/2 turn
anticlockwise.
CAUTION! Do not grind to heavily. This can destroy
the hardening of the teeth. Each turn of the adjuster
screws corresponds to a grinding depth of 0.75 mm.
The maximum grinding depth per sharpening is 0.1-
0.2 mm. If the bandsaw blade is very worn, grind
several times.
WARNING!
Risk of the grinding disc coming loose
and causing personal injury. Ensure the
power supply is connected so that the
grinding disc rotates in the right direc-
tion, that is, sharpening is performed
downwards-backwards.
!
WARNING!
Risk of damaging the grinding disc or
bandsaw blade, which can result in
personal injury. The grinding disc must
not be running during the procedure
set out in points 8-11 below.
!
