14
Figure 2 Figure 3
Figure 4
2. Adjustment of reverse cable (see Figure 3 and Figure 4)
1) Loosen the nut around the reverse cable.
2) Turn clockwise the screw until its exposed part from the handle pipe is of its shortest length.
3) Insert the reverse cable into the fork shaft on one side of the transmission box and make sure the
front end of the reverse cable is in the big hole of the fork shaft.
4) Turn counterclockwise the reverse shift fork shaft appropriately and insert the cable through the
Clutch cable
Cable lug
Fork shaft
To Next Page
