Data of standard torque
Parts name
Specification
Torque N·m
Spark plug
M10
15~20
Bolt on cylinder head cover
M6
8~12
Bolt for bracket of camshaft
M6
10~15
Fastening bolt of cylinder
body
M6
10~15
Fastening bolt for cylinder
head
M10
40~50
(Pre-fastening)
50~60
(Final-fastening)
Locking bolt for timing
driven sprocket wheel
M6
10~15
Fastening bolt of tensioner
M6
10~15
Bolt for oil tube
M8
10~15
Fastening nut of primary
driving gear
M12
90~100
Fastening nut of clutch
M12
70~80
Locking nut of impeller
M6
10~15
Controller valve comp. of
oil
M12
10~15
Fastening bolt of guiding
plate of ratchet
M6
8~12
Fastening bolt of rotor of
magnetor
M12
100~120
Fastening bolt of gearshift
drum plate
M6
10~15
Bolt of check plate
M6
10~15
Positioning bolt of gearshift
arm
M10
25~30
Oil drainage plug
M12
32~40
Pin axis of chain adjustor
M8
25~30
Except the key torque data in table above, others follow the table below:
Ref.No.
Parts name and
specification
Torque N·m
1
5mm Bolt and nut
5~7
2
6mm Bolt and nut
10~15
3
8mm Bolt and nut
15~20
4
10mm Bolt and nut
25~35
5
12mm Bolt and nut
30~40
6
5mm Screw
3.5~5
7
6mm Screw
8~12
