USE OF HYDRAULIC SYSTEM AND AUTOMATIC DRAFT AND
POSITION
CONTROL UNIT.
The hydraulic system stands for reliability and easy operation.
Fig. 23 - Hydraulic lifter
1. Control lever-2 . Stop
- 3. Response sensitivity
adjusting lever - 4. Pres-
sure limiting valve -
5.
Body - 6. Link support
wedge - 7. Selector lever
44
Fig. 24 - Remote
co n trol valve
1. Plug for use of
single-acting cylinder
- 2. Fitting for use
of double-acting cyl-
inder.
