Diagram Nº 11. Correct Flame Pattern
Diagram Nº 12. Incorrect Flame Pattern
Diagram Nº 10. Correct Flame Pattern
Optional Blower - DVBS (DV12) and DVBL (DV20)
Wiring Diagram
CAUTION: Label all wires prior to
disconnection when servicing
controls. Wiring errors can cause
improper and dangerous operation.
Verify proper operation after
servicing.
Permanently lubricated bearing
system.
WARNING: ELECTRICAL
GROUNDING INSTRUCTIONS.
This appliance is equipped with a
three-prong (grounding) plug for your
protection against shock hazard and
should be plugged directly into a
properly grounded three-prong re-
ceptacle. Do not cut or remove the
grounding prong from this plug.
Wiring Schematic
If any of the original wire as supplied
with the appliance must be replaced,
it must be replaced with 600 volt - 150
degree C. wire or its equivalent.
