Sign location: left side of frame hinge joint
Contents: it reminds the users to lock the
frame with fixing rod before transportation
and maintenance of machine, to avoid
accidents. Dismount the fixing rod before the
loader recovers its work, and place it in fixed
location.
1.2.4 WARNING SIGN OF LIFT ARM
Sign location: front end of lift arm
Contents: this sign reminds user that never
permit persons to stand below the moving lift
arm when operating lift arm to avoid
accidents.
1.2.5 SAFETY WARNING SIGN OF HINGE
Sign location: in the front and rear
hinging positions at the left side of
the front frame
1. Danger of crushing! Do not stand here when
the loader is turning, because the crushing may
lead to serious injury or death.
2. Danger of crushing! During the transport of
loader or the maintenance of hinge, the front and
rear frames of the loader shall be locked in order
to avoid dangers.
