Loop-O9500 SDH/SONET IMAP
SDH/SONET-MSTP
23
EoW with VoIP Technology
Data Networking
Router or Bridge Mode of Operation
Voice Gateway
SIPv2
Session Initiation Protocol Version 2 (RFC3261, 3262, 3263, 3264)
Voice Algorithms
G.711 (A-law and mu-law)
Attenuation
Gain Adjustments
Physical Interfaces
Two RJ-45 Port
Ethernet 100BaseT Interface (IEEE 802.3)
Two RJ-11 FXS Port
For Analog Circuit Telephone Device (Tip/Ring)
Subscriber Line Interface Circuit(SLIC)
Regulatory Compliance
FCC Part
15 Class B
CE
Mark
ICES-003
ESD level
Class B
Air: ± 8Kv
Contact: ± 4Kv
Power Supply
DC
Input Voltage: +5 VDC at 2.0 A Max.
Power Consumption
5 Watts
Indicator Lights
Indicator Lights/LED
Power
Storage Temperature
Storage
Temperature -13°F to 185°F (-25°C to 85°C)
Unit Dimensions
W x H x D
122.5mm x 43.7mm x 92.8mm
Ring Voltage
40 – 55 V
RMS
Configurable
Ring Frequency
10Hz – 40Hz
Ring Waveform
Trapezoidal and Sinusoidal
Max. Ringer Load
3 REN
On-hook/off-hook
Characteristics
On-hook voltage (tip/ring) : -50 V
NOMINAL
Off-hook current : 20 mA min
Terminating Impedance : 600 ohms
System Clock
Clock Source
Internal clock
4 aggregate lines clocks (STM-1/4 (OC-3/12))
External clocks: 2.048MHz or 2.048Mbps for STM-1/4, 1.544M bps for OC-3/12
Management Interface
LED
Multi colors
Console
Electrical: RS232
Connector: DB9S (DCE)
Protocol: Menu driven VT-100
SNMP
SNMPv1, v3 (RFC1213, RFC2863, RFC1493)
OSS interface
10/100BaseT FE (IEEE 802.3u )
NE/NE interface
DCC/HDLC/Ethernet type II
