Lorex LW2003 Specifications

LOREX
LIVE snap
Video Baby Monitor
LOREX
HOW IT WORKS
INSIDE THE BOX
MONITOR CHARGING CRADLECAMERA
POWER
ADAPTER
MEMORY
CARD
VIEW DAY OR NIGHT
SLEEP EASY
PRIVATE AND SECURE
Keep an eye on baby all night long
with crystal clear automatic night
vision. Check on little ones without
the risk of waking them up.
Sleep easy knowing that your baby
monitor is working around the clock.
Sound-Activated Alerts [VOX] turn
on the monitor's screen and audio
instantly upon detecting anything
from a faint whimper to a loud cry.
100% digital technology ensures a
private and secure signal between
the camera and handheld monitor.
GROWS WITH YOUR FAMILY
Add up to 3 additional cameras.
As your family grows, the LIVE snap
can expand right along with you.
Have a camera in the baby's room,
play room, living room, or even
pointing at the front door.
MULTIPLE VIEWING OPTIONS
Viewing modes include Single
Channel, Scan (switch between
single channels automatically), and
Quad Split-Screen.
CONSERVE ENERGY
Power Saving Mode allows you to listen-
in while keeping the monitor's screen
turned off to conserve battery life.
www.lorextechnology.com
LW2003 Series

Lorex LW2003 Specifications

General Specifications

transmission frequency	ISM 2, 400~2, 482 MHz
transmission power	18 dBm
unobstructed effective range	150 m / 450 ft
spread spectrum	FHSS
modulation mode	GFSK
operating temperature	0-50ºC / 32-122ºF
operating humidity	Less than 90%

Camera Specifications

imaging sensor type	CMOS
picture total pixels	H:240, V:320
minimum illumination	0 Lux (IR on)
night video distance	7 m / 22 ft
view angle	H: 38º V: 50º
image resolution	240 x 320 up to 25 fps
consumption current (max.)	390 mA
power supply	5 V DC
dimensions (W x D x H)	66 x 95 x 115 mm / 2.6 x 3.8 x 4.6"
weight	0.25 kg / 0.5 lbs

Receiver Specifications

LCD screen type	2.4 “ TFT-LCD
effective pixels	H: 240, V:320
receiving sensitivity	<.81 dBm
consumption current (max.)	250 mA
power supply	5 V DC
dimensions (W x D x H)	48 x 17 x 117 mm / 1.9 x 0.7 x 4.6"
weight	0.14 kg / 0.3 lbs

Product Information

package dimensions (LW2003)	199 x 69 x 135 mm / 7.8 x 2.7 x 5.3"
package cube (LW2003)	0.0025 cbm / 0.09 cbf
package weight (LW2003)	0.7 kg / 1.5 lbs
package dimensions (LW2003F)	200 x 69 x 139 mm / 7.9 x 2.7 x 5.5"
package cube (LW2003F)	0.0025 cbm / 0.09 cbf
package weight (LW2003F)	0.7 kg / 1.5 lbs
