Lorex LW2003 Specifications

LOREX
©2010 Lorex Technology Inc.
As our product is subject to continuous improvement, Lorex Technology &
subsidiaries reserve the right to modify product design, specifications & prices
without notice and without incurring any obligation. E&OE
3700 Koppers Street
Baltimore, Maryland 21227
USA
Lorex Technology Inc.
250 Royal Crest Court
Markham, Ontario L3R 3S1
Canada
1-11082010
LIVE snap
Video Baby Monitor
LOREX
SPECIFICATIONS
www.lorextechnology.com
PRODUCT INFORMATION
LW2003
English only Giftbox
UPC:
7-78597-20030-0
Package Dimensions:
(W x D x H)
199 x 69 x 135mm
7.8 x 2.7 x 5.3"
Package Cube:
0.0025cbm / 0.09cbf
Package Weight:
0.7kg / 1.5lbs
CONTENTS
1 x 2.4” LCD receiver
1 x Indoor camera with rechargeable battery
1 x Rechargeable battery for receiver
1 x Power adapter for camera
1 x Receiver charging cradle with power adapter
1 x microSD memory card
1 x SD memory card adapter
CAMERA
Imaging Sensor Type: CMOS
Picture Total Pixels: H:240, V:320
Minimum Illumination: 0Lux (IR on)
Night Video Distance: 7m / 22ft
View Angle: H: 38º V: 50º
Image Resolution: 240 x 320 up to 25fps
Consumption Current (Max.): 390mA
Power Supply: 5V DC
Dimensions (W x D x H): 66 x 95 x 115mm / 2.6 x 3.8 x 4.6"
Weight: 0.25kg / 0.5lbs
RECEIVER
LCD Screen Type: 2.4 “ TFT-LCD
Effective Pixels: H: 240, V:320
Receiving Sensitivity: <.81dBm
Consumption Current (Max.): 250mA
Power Supply: 5V DC
Dimensions (W x D x H): 48 x 17 x 117mm / 1.9 x 0.7 x 4.6"
Weight: 0.14kg / 0.3lbs
GENERAL
Transmission Frequency: ISM 2,400~2,482 MHz
Transmission Power: 18dBm
Unobstructed Effective Range: 150m / 450ft
Spread Spectrum: FHSS
Modulation Mode: GFSK
Operating Temperature: 0-50ºC / 32-122ºF
Operating Humidity: Less than 90%
ACCESSORIES
LW2003AC1
Add-On Camera
UPC:
7-78597-20031-7
Package Dimensions:
(W x D x H)
120 x 65 x 120mm
4.72 x 2.56 x 4.72”
Package Cube:
0.0009cbm / 0.33cbf
Package Weight:
0.3kg / 0.6lbs
LW2003F
Universal Sleeve
UPC:
7-78597-20034-8
Package Dimensions:
(W x D x H)
200 x 69 x 139mm
7.9 x 2.7 x 5.5"
Package Cube:
0.0025cbm / 0.09cbf
Package Weight:
0.7kg / 1.5lbs

Lorex LW2003 Specifications

General Specifications

transmission frequency	ISM 2, 400~2, 482 MHz
transmission power	18 dBm
unobstructed effective range	150 m / 450 ft
spread spectrum	FHSS
modulation mode	GFSK
operating temperature	0-50ºC / 32-122ºF
operating humidity	Less than 90%

Camera Specifications

imaging sensor type	CMOS
picture total pixels	H:240, V:320
minimum illumination	0 Lux (IR on)
night video distance	7 m / 22 ft
view angle	H: 38º V: 50º
image resolution	240 x 320 up to 25 fps
consumption current (max.)	390 mA
power supply	5 V DC
dimensions (W x D x H)	66 x 95 x 115 mm / 2.6 x 3.8 x 4.6"
weight	0.25 kg / 0.5 lbs

Receiver Specifications

LCD screen type	2.4 “ TFT-LCD
effective pixels	H: 240, V:320
receiving sensitivity	<.81 dBm
consumption current (max.)	250 mA
power supply	5 V DC
dimensions (W x D x H)	48 x 17 x 117 mm / 1.9 x 0.7 x 4.6"
weight	0.14 kg / 0.3 lbs

Product Information

package dimensions (LW2003)	199 x 69 x 135 mm / 7.8 x 2.7 x 5.3"
package cube (LW2003)	0.0025 cbm / 0.09 cbf
package weight (LW2003)	0.7 kg / 1.5 lbs
package dimensions (LW2003F)	200 x 69 x 139 mm / 7.9 x 2.7 x 5.5"
package cube (LW2003F)	0.0025 cbm / 0.09 cbf
package weight (LW2003F)	0.7 kg / 1.5 lbs
