Lotus 2004 ELISE User Manual

Lotus Service Notes Section TDQ
Page 2
DIMENSIONS
Overall length - Elise 3785 mm
- Exige 3797 mm
Overall width - exc. mirrors - Elise 1719 mm
- Exige 1727 mm
- inc. mirrors 1850 mm (approx.)
Overall height (at kerb weight) - Elise 1117 mm
- Exige 1159 mm
Wheelbase 2300 mm
Track - front 1457 mm
- rear 1507 mm
Ground clearance (mid-laden) - except std. USA 130 mm
- std. USA 135 mm
Front overhang - Elise 783 mm
- Exige 805 mm
Rear overhang - Elise 702 mm
- Exige 692 mm
Approach angle (at kerb) 13.5°
Departure angle (at kerb) 23°
Unladen weight - 111R/Elise R - total 860 kg >
(lightest) - front 327 kg > incl. full fuel tank
- rear 533 kg >
- Elise S - total 862 kg }
(lightest) - front 328 kg } incl. full fuel tank
- rear 534 kg }
- USA Elise - total 912 kg )
(heaviest) - front 344 kg ) incl. full fuel tank
- rear 568 kg )
- non-USA Exige - total 875 kg >
- front 328 kg > incl. full fuel tank
- rear 547 kg >
- non-USA Exige S- total 935 kg }
- front 355 kg } incl. full fuel tank
- rear 580 kg }
- USA Exige - total 920 kg )
- front 350 kg ) incl. full fuel tank
- rear 570 kg )
Max. weight - 111R/R, Exige - total 1166 kg >
- front 443 kg > incl. occupants & luggage
- rear 723 kg >
- Elise S - total 1126 kg }
- front 428 kg } incl. occupants & luggage
- rear 698 kg }
- USA Elise - total 1162 kg )
- front 441 kg ) incl. occupants & luggage
- rear 721 kg )
- non-USA Exige S- total 1199 kg >
- front 456 kg > incl. occupants & luggage
- rear 743 kg >
Trailer towing Not permissible
CAPACITIES
Engine oil - refill inc. filter 4.4 litre
(+ 3.5 litre if front mounted oil coolers are drained)
High/low dipstick mark difference 1.5 litre
Transmission oil 2.3 litre
Fuel tank 43.5 litre
