Lotus 2004 ELISE User Manual

Lotus Service Notes Section TDQ
Page 6
CLUTCH
Type Single dry plate. Diaphragm spring cover.
Hydraulic release.
Friction plate diameter 215 mm
Diaphragm finger clearance 1.00 mm
Diaphragm finger height - new 37.5 - 32.1 mm
- service limit 42.75 mm
Friction plate thickness - new 7.4 - 6.9 mm
- service limit 5.6 mm
Rivet depth - new 1.00 mm
- service limit 0.20 mm
Friction plate run-out - new 0.80 mm
- service limit 1.00 mm
Pressure plate warp - service limit 0.15 mm
BRAKES
Brake discs Cast iron, curved vane ventilated, cross-drilled discs
on all four wheels.
Calipers - front A.P. Racing, aluminium alloy body, one pair of
opposed pistons
- rear Brembo, cast iron, single piston sliding rear calipers
Disc size - front & rear 288 mm
Operation Tandem master cylinder with vacuum servo and
Kelsey Hayes EBC430 Anti-lock system
Parking brake Cable operation of rear calipers, self adjusting for
pad wear.
STEERING
Type Rack and pinion
Turns, lock to lock 2.8
Gear ratio 15.8:1
Rack height plate 6 notch
FUEL CONSUMPTION 1ZZ-GE 2ZZ-GE
1999/100/EC - urban 11.3 l/100km 12.1 l/100km
- extra urban 6.5 l/100km 6.8 l/100km
- combined 8.3 l/100km 8.8 l/100km
