P01.10 Backup command mode MODE A OFF
MODE A
MODE B
MODE C
P01.11 Backup control pulse duration s 3.0 1.0 - 60.0
P01.12 Normal state remote tripping NOR NOR - REV
P01.13 Normal state IS feedback NOR NOR - REV
P01.14 Normal state backup feedback NOR NOR - REV
P01.01 – Nominal voltage of the system. For a system with VL-L voltage control set line voltage, for a system with VL-N voltage control set phase voltage.
P01.02 – Type of connection and type of voltage control. Program in line with the wiring.
P01.03 – IS energising delay time after applying voltage to PMVF52.
P01.04 – Defines the function of the OUT3 output from those listed. The output is understood to be activated when conditions are normal (threshold not exceeded, alarm not active, etc.).
P01.05 – Defines the function of the OUT4 output (on EXM module, if mounted) from those listed. The output is understood to be activated when conditions are normal (threshold not exceeded, alarm not active, etc.).
P01.06 – Defines the function of the OUT5 output (on EXM module, if mounted) from those listed. The output is understood to be activated when conditions are normal (threshold not exceeded, alarm not active, etc.).
P01.07 – Defines the function of the INP5 input from those listed.
P01.08 – Defines the function of the INP6 input (on EXM module, if mounted) from those listed.
P01.09 – Defines the function of the INP7 input (on EXM module, if mounted) from those listed.
P01.10 – Defines the backup control mode, according to the logic in the Backup Activation Modes diagram on the final pages of this manual. If the backup is not used, set to OFF.
P01.11 – Backup opening pulse duration, when used in MODE C.
P01.12 – Defines the logic of normal status of the remote tripping if normal (NOR) or inverted (REV) with respect to the contact. For compliance with CEI 0-21 use NOR.
P01.13 – Defines the logic of normal status of the IS feedback if normal (NOR) or inverted (REV) with respect to the contact. For compliance with CEI 0-21 use NOR.
P01.14 – Defines the logic of normal status of the backup feedback if normal (NOR) or inverted (REV) with respect to the contact. For compliance with CEI 0-21 use NOR.
P02.06 – If set to OFF, the display always remains on the page where the user left it. If set to a value, after this time the display returns to the page set with P02.07.
P02.07 – Abbreviation for the start page on switching on and that the display returns to automatically once the time P02.06 since a button was last pressed has elapsed.
P02.08 – Type of sub-page that the display returns to after P02.06 has elapsed.
M02 – UTILITY UoM Default Range
P02.01 Language Italiano English
Italiano
P02.02 LCD contrast % 60 0-100
P02.03 Display backlighting intensity HIGH % 100 0-100
P02.04 Display backlighting intensity LOW % 30 0-50
P02.05 Low backlight delay s 30 5-600
P02.06 Default page return s 60 OFF / 10-600
P02.07 Default page SPI measurements SPI – SYN – EVE ...
P02.08 Default sub-page GR IN / HI / LO / AV / GR
P02.09 Display update time s 0.5 0.1 – 5.0
P03.01 – If set to OFF, password management is disabled.
P03.02 – With P03.01 active, value to specify to activate user-level access. See Password-Protected Access section on page 5.
P03.03 – As P03.02, with reference to Advanced-level access.
M03 – PASSWORD UoM Default Range
P03.01 Enable passwords ON OFF-ON
P03.02 User-level password 1000 0-9999
P03.03 Advanced-level password 2000 0-9999
P04.01...P04.16 – Adjustment of trip thresholds and delay times defined by the CEI 0-21 standard.
P04.17 – Maximum IS opening waiting time, before IS locking is recognised with consequent backup opening command.
P04.18 – Local control setting via parameter. Operates in OR with the input of the corresponding function.
P04.19 – IS restore (reset) time. IS reclosing delay time after all thresholds are ok again.
M04 –SPI THRESHOLDS UoM Default Range
P04.01 MAX V threshold 59.S2 % 115 100 - 130
P04.02 MAX V threshold 59.S1 % 110 100 - 120
P04.03 MIN V threshold 27.S1 % 85 20 - 100
P04.04 MIN V threshold 27.S2 % 15 5 - 100
P04.05 MAX V delay 59.S2 s 0.20 0.05 - 5.00
P04.06 MAX V delay 59.S1 s 3.00 0.20 - 10.00
P04.07 MIN V delay 27.S1 s 1.5 0.05 - 5.00
P04.08 MIN V delay 27.S2 s 0.20 0.05 - 5.00
P04.09 MAX F threshold 81>.S2 Hz 51.50 50.0 - 52.0
P04.10 MAX F threshold 81>.S1 Hz 50.20 50.0 - 52.0
P04.11 MIN F threshold 81<.S1 Hz 49.80 47.0 - 50.0
P04.12 MIN F threshold 81<.S2 Hz 47.50 47.0 - 50.0
P04.13 Long MAX F delay s 1.00 0.05 - 5.00
P04.14 Short MAX F delay s 0.10 0.05 - 5.00
P04.15 Short MIN F delay s 0.10 0.05 - 5.00
P04.16 Long MIN F delay s 4.00 0.05 - 5.00
P04.17 Backup activation delay s 0.5 0.1 – 10.0
P04.18 Local control OFF OFF - ON
P04.19 SPI restore time (reset) s 0.08 0.04 – 300.00
