Lovato DMG510 - RS485 Interface Information; RS485 Connection Details; Mechanical Dimensions and Panel Cutout; Terminal Positioning Guide

I604 GB I 09 19 31100442
5
T
ERMINALS POSITION
Aux supply
100-240V~
50/60Hz
1W
3VA
V Input 100-480V~ 50/60Hz
I Input 0,025-5A~ RS485
I3
I2
I1
A
VN
V3
V2
V1
B
A2
A1
Aux supply
100-240V~
50/60Hz
1W
3VA
V Input 100-480V~ 50/60HzI Input 0,025-5A~ RS485
I3
I2
I1
A
VN
V3
V2
V1
B
A2
A1
M
ECHANICAL DIMENSIONS AND FRONT PANEL CUTOUT (mm)
96
96
92
92
65
55
8.5
D
MG500 DMG510
R
S485 INTERFACE
DMG5... n°1
Max 1200m
DMG5... n°31
MASTER
RS485
A B
RS485
A B
1
20R
RS485
A B
1
20R
