May, 2013 Page 36 of 52 949-1194 Rev. 7
S 2 r E Set Point 2 Reset. Select O n O F or H o l d .
O n O F Output will automatically reset when process passes back through
S P 2 d .
H o l d Manual Reset. Reset (acknowledge) by simultaneously pressing the
INDEX & DOWN ARROW keys for 3 seconds.
S 2 P i Set Point 2 Power Interrupt. Select O n or O F F .
O n Alarm Power Interrupt is O n . Output will automatically reset on power-
up if no alarm condition exists.
O F F Alarm Power Interrupt is O F F . Output will be in the alarm condition on
power-up regardless of condition of process.
S 2 i H Set Point 2 Inhibit: Select O n or O F F .
O n Alarm Inhibit is O n . Alarm action is suspended until the process value
first enters a non-alarm condition.
O F F Alarm Inhibit is O F F .
S 2 L P Set Point 2 Lamp: Select O o n or O o F F .
O o n Lamp ON when Output is ON.
O o F F Lamp OFF when Output is ON.
ALARM TYPE AND ACTION (if alarm function is present)
Caution: In any critical application where failure could cause expensive
product loss or endanger personal safety, a redundant limit controller is
required.
When setting an alarm value for an absolute alarm (A 1 t = A b S ), simply set the value at
which the alarm is to occur.
When setting the alarm value for a deviation alarm (A 1 t = d E ), set the difference in value
from the Set Point desired. For example if a low alarm is required to be 5 degrees below
the Set Point, then set A 1 L o to -5. If a high alarm is required 20 degrees above the Set
Point, then set A 1 H i to +2 0 . If the Set Point is changed, the alarm will continue to hold the
same relationship as originally set.
