Lovol Phaser Series - Page 81

II Introduction of main elements
3.1 Sensors
Signal of rotational speed: acquire the signal at the W point of the little generator.
(A) Accelerator position sensor
It is mounted an the fuel pump and the signal is acquired at the handle shaft. Its figure and parameters are as follows:
13.05
throttle position sensor
fuel injection pump
