User Guide for SpeedControl E 1045
• LS Control A/S • Industrivej 12 • DK –4160 Herlufmagle Page 4
• Tel: +45 5550 5550 • Fax:+45 5550 2265 • www.lscontrol.com • lsc@lscontrol.dk
Technical Specifications
E1045-1500W-5.5A
E1045-2000W-6.5A
Supply Voltage
Uin = 230VAC ±10% - 50Hz
Uin = 230VAC ±10% - 50Hz
Supply Current
Max. Iin = 10A
Max. Iin = 16A
Supply Power
Max. 1500W
Max. 2000W
Motor Voltage
3 x AC - 0 - Uin
3 x AC - 0 – Uin
Motor Current
Max. 5,5A
Max. 6,5A
Motor Frequency
0 – 300 Hz
0 – 300 Hz
16Vdc output
100mA
100mA
10Vdc output
30mA
30mA
0 – 10V input
0 – 10V, Ri = 7 kOhm.
0 – 10V, Ri = 7 kOhm.
Alarm Relay
Max. 30Vdc/3A & 230VAC/3A
Max. 30Vdc/3A & 230VAC/3A
Operating Temperature
0 – 40°C
0 – 40°C (active cooling over 1650W)
Modbus A
Net plus
Net plus
Modbus B
Net minus
Net minus
Modbus C
Net GND
Net GND
EMC
The frequency converter (IP54) complies with the standard of electrical Power Drive Systems. The
frequency converter is classified as a Power Drive System (PDS) of ”category C2” (EN 61800 – 3).
• EN 61800 – 3:2005 – Adjustable speed electrical power drive systems - Part 3: EMC requirements
and specific test methods.
• EN 61800 – 3/A1:2012 – Adjustable speed electrical power drive systems - Part 3: EMC
requirements and specific test methods.
• EN 61800 – 5 – 1:2007 – Adjustable speed electrical power drive systems - Part 5-1: Safety
requirements - Electrical, thermal and energy.
If a frequency converter is purchased in no enclosure (IP00), LS Control can’t ensure that the frequency
converter complies with the above standards.
Warnings
Before the frequency converter is taken into use, verify that the frequency converter specifications are
compatible with the mains to which it is going to be connected. Furthermore verify that the motor is
suitable for frequency converter connection and that it is in compliance with the frequency converter
specifications.
Check the place of installation for any special requirements and precautions which must be observed during
installation, commissioning or operation. The frequency converter must be supplied through a mains switch
with at least 3mm breaker space between all conductors according to IEC364. The fuse installed in the
electrical switchboard must be 13A or less for E1045-1500 and 16A or less for E1045-2000. The frequency
converter must always be connected to yellow/green grounding conductor (PE) in supply.
