3 -37
HST
1. Hydraulic filter
2. Steering pump
3. Steering unit
4. Steering cylinder
5. Independent PTO valve
6. HST filter
7. Oil cooler
8. HST unit
9. Hydraulic lift pump
10. Front outlet valve or
Front loader valve (optional)
11. Remote control valve (optional)
12. Hydraulic lift control valve
13. Down speed control valve
14. Safety valve
15. Hydraulic lift cylinder
16. Oil tank
