4 -31

② Rear wheel track - 11.2-24 8PR with rim & disk (W10x24)

Unit : mm (inch)

1139(44.9 in.)

N/A

1167(46.0 in.)

1215(47.9 in.)

1321(52.0 in.)

1091 (43.0 in.)

(Standard track)
