LS tractor MT468

To Next Page

To Previous Page

2 -2

② Cabin type

Instrument panel

Steering

wheel

Driver’s

Seat

Sub step

Head lights

Bonnet (Hood)

Front ballast weight

(optional)

Front axle

Fender

Fuel tank

Cabin (ROPS)
