Insert the pipe into the clamps and tighten the M8 nuts in such a way that the pipe is sloping of
about 1% between the inlet and outlet.
Slope is driven by the height of threaded bar in the horizontal installation and by the position in the
stirrup loop in the vertical installation.
With KW only, lower position shall be opposite to the water inlet to facilitate the water discharge.
horizontal installation
vertical installation
IN
OUT
IN
OUT
